VF85 High euismod Vertical Machining Center Fabricatores, Societas

CNC EDM nobis Conventional EDM: Imperium, Cura, Setup, ac Pretium Differentiae -2026 -11-04

Duae machinae morientes mersae iuxta eandem tabulam sedere possunt, eadem generante scrinio et simili vestigio, et adhuc in usu quotidiano instrumenta prorsus diversa sunt. Discrimen decretorium...

How Does EDM Machining Work? Scintilla Gap, Dielectric et Physicorum Dimittite -2026 -10-28

A 0,3 mm intra angulum in fundo 58 HRC H13 insertum mori punctum est ubi milling optionis esse desinit. Radius angulus minor est omni dromone practico, materia carbidam extremum in uno saltu int...

CNC Wire Cut EDM Machina: Specs, Sumptus ac Rector pro Mold officinae -2026 -10-21

D2 mor- tuntur indurata, ferrum carbide, extrusio moriuntur inserta — semel hae partes exeunt de fornace ad 58 ad 62 HRC, super molendo et stridor tardus fit et pretiosus. A CNC filum incisum ED...

EDM technologia: Applications, Electio Criteria, ac Gubernatio Practica -2026 -10-20

Picture a hardened H13 mold insert with a 0.8 mm deep rib and a square internal corner that no end mill can reach. The cavity has already been milled, but the last details need a process that cu...

EDM solvendi Machining Explicata: Processus, Tooling et Machina Electio -2026 -10-14

A 0,6 mm intra angulum in forma durata H13 inserta copiae molendini minuti in 52 HRC chalybe, et hoc est officium instrumenti-fractionis magis declinare tabernae. EDM emissi machinationem in cir...

Model	Unitas	VF85
Travel (X/Y/Z)	mm	800/550/550
Opus mensam dimensionem	mm	1000x550
T-slot	mm	5-18Tx90
Maximum onus	kg	600
Procul ab fuso nasus ad mensam	mm	120-670
Distat a centro fusi ad columnam veriticam	mm	590
Fusum
Taper		BT40
Celeritas rotating	rpm	12000/1000 (Libitum)
FANUC Motor power	kW	7.5/11/15
MITSUBISHI Motor potentia	kW	7.5/11/15
Tres-axis
FANUC Motor potentia (X/Y/Z)	kW	1.8/1.8/3.0
MITSUBISHI Motor potentia (X/Y/Z)	kW	2.0/2.0/3.0
Rail specificationem (X / Y / Z)	mm	Roller: 35/45/45
Numerus iunctae (X/Y/Z)	Pc	4/4/6
stupra magnitudine	mm	JIS C3: Φ40
G01 Feed rate	mm/min	1-1000
G01 Celeri velocitate percurre (X/Y/Z)	m/min	48/48/48
Positional accuracy	mm	±0.005/300
Repetita positioning accuracy	mm	±0.003/300
Instrumentum magazine
Manipulator bibliotheca	pce.	24
Tempus mutantur instrumentum dromonem	s	1.3-1.8
Max instrumentum longum	mm	300
Diameter max instrumentum (omnia instrumenta foramina plena sunt instrumentorum)	mm	78
Diameter instrumentum max (instrumentum foramina vacua sunt in dextra laevaque)	mm	120
Maximum pondus instrumentum dromonem	kg	8
Other
Apparatus pondus	t	5.4
Potestas demanda	kVA	20
Pressura demanda	kgf/cm²	6
Forma dimensionis	mm	2580x2764x2943
