M512AHD/516AHD/620AHD Subtilitas Superficies Molere Machina Fabricatores, Societas

CNC EDM nobis Conventional EDM: Imperium, Cura, Setup, ac Pretium Differentiae -2026 -11-04

Duae machinae morientes mersae iuxta eandem tabulam sedere possunt, eadem generante scrinio et simili vestigio, et adhuc in usu quotidiano instrumenta prorsus diversa sunt. Discrimen decretorium...

How Does EDM Machining Work? Scintilla Gap, Dielectric et Physicorum Dimittite -2026 -10-28

A 0,3 mm intra angulum in fundo 58 HRC H13 insertum mori punctum est ubi milling optionis esse desinit. Radius angulus minor est omni dromone practico, materia carbidam extremum in uno saltu int...

CNC Wire Cut EDM Machina: Specs, Sumptus ac Rector pro Mold officinae -2026 -10-21

D2 mor- tuntur indurata, ferrum carbide, extrusio moriuntur inserta — semel hae partes exeunt de fornace ad 58 ad 62 HRC, super molendo et stridor tardus fit et pretiosus. A CNC filum incisum ED...

EDM technologia: Applications, Electio Criteria, ac Gubernatio Practica -2026 -10-20

Picture a hardened H13 mold insert with a 0.8 mm deep rib and a square internal corner that no end mill can reach. The cavity has already been milled, but the last details need a process that cu...

EDM solvendi Machining Explicata: Processus, Tooling et Machina Electio -2026 -10-14

A 0,6 mm intra angulum in forma durata H13 inserta copiae molendini minuti in 52 HRC chalybe, et hoc est officium instrumenti-fractionis magis declinare tabernae. EDM emissi machinationem in cir...

Model	Unitas	M512AHD	M516AHD	M620AHD
Superficiem mensam opus	mm	500×1200	500×1600	2000×600
Maximilianus. Mensa itinerantur	mm	1350	1750	2200
Maximilianus. Crucis itinerantur	mm	540	540	670
Intervallum inter mensam superficiem et colum centrum	mm	590	590	750
Maximilianus. Mensa onus	kg	800	1000	2500
T-Solt (Number-width)	mm	3×16	3×16	18×3
Mensa celeritas	m/min	8-25	8-25	5-25
handwheel 1 gard / 1 rev	mm	0.02mm/eget 5mm/r	0.02mm/eget 5mm/r	0.01mm/eget 1mm/r
Automatic de sellae crossfeed	mm	0.5-12	0.5-12	0.1-25.6
Virtus crucis feed 50HZ/60HZ	mm/min	1250/1500	1250/1500	990/1190
Moles rotae dimensiones	mm	355 40× 127	355 40× 127	350(400)×40×127
Fusum celeritatem 50HZ/60HZ	rpm	1450/1740	1450/1740	1450/1740
Vertical handwheel 1 gard / 1 rev	mm	0.002mm/grid 0.5mm/r	0.002mm/grid 0.5mm/r	0.001mm/grid 0.1mm/r
Lorem in feed rate	mm	-/0.005-0.04	-/0.005-0.04	-/0.005-0.04
Virtus caput increment	mm/min	230	230	230
Fusum motricium	kw	7.5	7.5	7.5
Vertical motor	w	370	370	370
Hydraulica motoris	kw	2.2	2.2	2.6
Collectio pulveris motricium	w	550	550	550
Coolant motricium	w	90	90	90
Motricium Crossfeed	w	370	370	370
Tabulatum spatium	mm	4445×2200	5810×2445	8500×2800
Stipare dimensiones	mm	3390×2255×2225	3890×2255×2225	6500×2600×2100
Net pondus	kg	5000	6000	8500
